Alsterstreek		#151 Posted : 24 April 2017 12:41:52(UTC) Retweet
Joined: 16/11/2011(UTC) Posts: 5,753 Location: Hybrid Home		Same operational effect strictly at water level with less ramp building and shortened outer loop = 12 m and inner loop = 5 m (ignoring future station trackage, respectively). Serving suggestion:
		Greetz - Ak My current "layout": https://www.marklin-user...aigne-Project#post592818
4 users liked this useful post by Alsterstreek		hvc, Irish Rail, TrainIride, Jimmy Thompson
User Profile View All Posts by User View Thanks

Alsterstreek		#152 Posted : 27 April 2017 13:11:44(UTC) Retweet
Joined: 16/11/2011(UTC) Posts: 5,753 Location: Hybrid Home		Adding some interest with the help of a mine next to the lower main line plus a high line coming from the "off"?
		Greetz - Ak My current "layout": https://www.marklin-user...aigne-Project#post592818
3 users liked this useful post by Alsterstreek		Irish Rail, TrainIride, Jimmy Thompson
User Profile View All Posts by User View Thanks

Alsterstreek		#153 Posted : 27 April 2017 13:41:08(UTC) Retweet
Joined: 16/11/2011(UTC) Posts: 5,753 Location: Hybrid Home		For reference: Former DRGW Eagle River line south of Belden. Belden mine siding just next to the DRGW main line track.
		Greetz - Ak My current "layout": https://www.marklin-user...aigne-Project#post592818
4 users liked this useful post by Alsterstreek		grnwtrs, Irish Rail, TrainIride, Jimmy Thompson
User Profile View All Posts by User View Thanks

Alsterstreek		#154 Posted : 27 April 2017 15:20:24(UTC) Retweet
Joined: 16/11/2011(UTC) Posts: 5,753 Location: Hybrid Home		In case somebody wondered what the station could look like: Just an initial sketch... The idea of combining two „mattress-size“ foam board-base modules for the ease of transport, tracks to connect both modules in a confined area at one end for the ease of separation. One board is to represent a canyon scene, loosely inspired by the former DRGW Eagle River line south of Belden. For the board on the other side of a central divider I envisage a stacked terminal railroad, a parking space, stuffed with rolling stock. Return blobs = 4 m long = EMD F7 ABBA + 16 tin plate 50 feeters (or 20 plastic 40 feeters) + caboose. Then, there are two separate racetracks (thus each river bank served by another line). Matching tunnel portals are marked with letters. Red letters indicate the first circuit and violet letters indicate the second one. The only ramp is (partially) hidden under the elevated town; the double-track ramp allows for train meets. Lower level stub tracks extending under the town and elevated passenger station are meant for freight cars. Stub tracks on the upper level are meant for passenger trains. Trackage in the lower left hand corner is for displaying large motive power. So flat, good, square fun.
		Greetz - Ak My current "layout": https://www.marklin-user...aigne-Project#post592818
5 users liked this useful post by Alsterstreek		Robert Davies, grnwtrs, Irish Rail, TrainIride, Jimmy Thompson
User Profile View All Posts by User View Thanks

Alsterstreek		#155 Posted : 12 May 2017 16:55:30(UTC) Retweet
Joined: 16/11/2011(UTC) Posts: 5,753 Location: Hybrid Home		Forum member BrandonVA made me think: Why note evolve on an existing "successful" design? So, working from my L-shaped layout "Badland", I came up with improvements. 1. Convert mainline from double to single track, which: - is more prototypical for US railroads; - makes the line look longer; - leaves more room for landscaping. 2. Fill the access bay with a Styrofoam hill, allowing to lay new rails on track level 4 to create a long siding for train meets (currently happening on the double track section). to shift train meets which took place on the former double track section.
		Greetz - Ak My current "layout": https://www.marklin-user...aigne-Project#post592818
3 users liked this useful post by Alsterstreek		Irish Rail, TrainIride, Jimmy Thompson
User Profile View All Posts by User View Thanks

Alsterstreek		#156 Posted : 12 May 2017 17:08:18(UTC) Retweet
Joined: 16/11/2011(UTC) Posts: 5,753 Location: Hybrid Home		Then, by altering the track level 0 the following goals are achieved - two trains running on two separate circuits (red and green); - two tracks separated by a river. Considering that higher track levels are overlaying the lowest one, the visible parts of track level 0 would be as follows.
		Greetz - Ak My current "layout": https://www.marklin-user...aigne-Project#post592818
4 users liked this useful post by Alsterstreek		grnwtrs, Irish Rail, TrainIride, Jimmy Thompson
User Profile View All Posts by User View Thanks

Alsterstreek		#157 Posted : 12 May 2017 17:15:04(UTC) Retweet
Joined: 16/11/2011(UTC) Posts: 5,753 Location: Hybrid Home		Rotating the last sketch allows for comparison with a historic photo of the former Belden mine siding on the - now dormant - Tennessee Pass main line in Colorado.
		Greetz - Ak My current "layout": https://www.marklin-user...aigne-Project#post592818
4 users liked this useful post by Alsterstreek		grnwtrs, Irish Rail, TrainIride, Jimmy Thompson
User Profile View All Posts by User View Thanks

Alsterstreek		#158 Posted : 25 July 2017 15:30:35(UTC) Retweet
Joined: 16/11/2011(UTC) Posts: 5,753 Location: Hybrid Home		July 1956 issue of MODEL TRAINS. The cartoonist is R.O. Gilbert
		Greetz - Ak My current "layout": https://www.marklin-user...aigne-Project#post592818
5 users liked this useful post by Alsterstreek		grnwtrs, Irish Rail, TrainIride, Jimmy Thompson, Bosse
User Profile View All Posts by User View Thanks

Alsterstreek		#159 Posted : 27 July 2017 23:50:11(UTC) Retweet
Joined: 16/11/2011(UTC) Posts: 5,753 Location: Hybrid Home		As I have to live up to my reputation, I dreamt up another ultimate layout condensation - see snapshots. Max. size 4 x 8 ft. The evolution: 1. The starting point is - what else - a dogbone. To save space - what else - the station area is placed inside one of the reversing loops. When having both loops visually separated and throwing the station loop turnout alternatively into either direction, and when viewing only the station loop area, the illusion is created that a train leaves the station to X-town and returns from X-town after some time, before leaving to Y-town before later returning from Y-town. In a similar manner, the same illusion would be created for the stationless mainline loop behind a scenic divider. 2. How to cope with long trains on a limited station surface? Coiling. On a helix. 3.Then condense the entire contraption by folding and twisting. Finetuning: Conceal the station helix (or helix station), display an intimidating station throat and have station tracks disappear in the scenic divider under a faux station façade and/or road bridge in front of a city backdrop (has been done before, I was told). Wham, that's whimsical model railroading. Full roundtrip form would be 20 m.
		Greetz - Ak My current "layout": https://www.marklin-user...aigne-Project#post592818
4 users liked this useful post by Alsterstreek		Irish Rail, CanadianKid, TrainIride, Jimmy Thompson
User Profile View All Posts by User View Thanks

Alsterstreek		#160 Posted : 29 July 2017 15:31:26(UTC) Retweet
Joined: 16/11/2011(UTC) Posts: 5,753 Location: Hybrid Home		Note to myself on basic functionality of above design. When having a dogbone with reversing loops, the latter need to be concealed for the sake of plausibility. This is eating precious space. The idea is to adapt a dogbone for making it socially acceptable to leave one or even both reversing loops in the open. A station would be sitting in the loop area instead of being located in between the loops and would still see a train departing into one direction and see the same train returning from the same direction. Both large and small layouts could benefit from this approach. Sprung turnouts allow for "mechanic automation". Prototypical train running appearance to be reached by either concealing one blob and the hidden blob taking over shadow station duties... ... or having a "solid" view block separating both blobs. Blobs do *not* need to be equally sized. One blob could have a train-lenght size and the other one could fill a room with book shelf right of way running along the walls. Alternatively, blobs could be stacked, twisted and folded. The "Hosentraeger"double crossover could be placed in a curve etc.
		Greetz - Ak My current "layout": https://www.marklin-user...aigne-Project#post592818
5 users liked this useful post by Alsterstreek		CanadianKid, kimballthurlow, Irish Rail, TrainIride, Jimmy Thompson
User Profile View All Posts by User View Thanks

Alsterstreek		#161 Posted : 09 September 2017 14:15:45(UTC) Retweet
Joined: 16/11/2011(UTC) Posts: 5,753 Location: Hybrid Home		Pragmatism might be needed to make ends meet when space is limited.
		Greetz - Ak My current "layout": https://www.marklin-user...aigne-Project#post592818
2 users liked this useful post by Alsterstreek		TrainIride, Jimmy Thompson
User Profile View All Posts by User View Thanks

Alsterstreek		#162 Posted : 09 September 2017 14:22:33(UTC) Retweet
Joined: 16/11/2011(UTC) Posts: 5,753 Location: Hybrid Home		E.g., for a study like this one on 100 x 200 cm: Has it been tested? Yes, sort of: :o)
		Greetz - Ak My current "layout": https://www.marklin-user...aigne-Project#post592818
4 users liked this useful post by Alsterstreek		madhu.gn.71, dennisb, TrainIride, Jimmy Thompson
User Profile View All Posts by User View Thanks

Alsterstreek		#163 Posted : 30 September 2017 14:58:28(UTC) Retweet
Joined: 16/11/2011(UTC) Posts: 5,753 Location: Hybrid Home		Trying to combine my beloved complicated station throats with a separate landscape by combining two modules is too space consuming for my taste. So I was thinking of stacking the two modules, dreaming up the 100 x 200 cm "Train-Room Mush-Room". A basement with a visible station throat and concealed coiling area for long trains crowned by an attic with a landscaped section.
		Greetz - Ak My current "layout": https://www.marklin-user...aigne-Project#post592818
3 users liked this useful post by Alsterstreek		TrainIride, kimballthurlow, Jimmy Thompson
User Profile View All Posts by User View Thanks

Alsterstreek		#164 Posted : 30 September 2017 15:08:50(UTC) Retweet
Joined: 16/11/2011(UTC) Posts: 5,753 Location: Hybrid Home		For the landscaped attic, I envisage to elaborate on an earlier design to make it fit on 100 x 200 cm. A quick mock-up demonstrates the feasibility on 100 x 200 cm. Flat: Elevated: All curves with easements. Upper return blob not included yet. Edited by user 24 May 2018 12:06:08(UTC)  | Reason: typo
		Greetz - Ak My current "layout": https://www.marklin-user...aigne-Project#post592818
2 users liked this useful post by Alsterstreek		TrainIride, Jimmy Thompson
User Profile View All Posts by User View Thanks

Alsterstreek		#165 Posted : 01 October 2017 01:07:10(UTC) Retweet
Joined: 16/11/2011(UTC) Posts: 5,753 Location: Hybrid Home		First train-room mush-room basement attempts, starting with an oval helix with sidings coiled around the latter. Mind you that eventually only the outer two sidings shall be visible, while the "distribution clockwork" inside is concealed in the support structure on which the landscaped "attic" is supposed to rest. Then a trial incorporating the inverted return loop concept presented here: https://www.marklin-user...d-innovations#post537826 The inverted return loop looks quite pleasant, but the overall result does not convince me. The curved turnouts behind the overpass are difficult to reach. Furthermore, the trackage looks not "fluid" enough. Both trials deliver toy-like results, and styrofoam characteristics do nor allow for a connection to the attic. In addition, inner "distribution clockwork" turnouts are hard to reach. And most prominently, my minimum siding storage capacity requirement of a EMD F7 ABBA + 16 tin plate box cars (50 ft) + 1 caboose is not met: The inner siding capacity is one box car short, respectively.
		Greetz - Ak My current "layout": https://www.marklin-user...aigne-Project#post592818
3 users liked this useful post by Alsterstreek		TrainIride, Danlake, Jimmy Thompson
User Profile View All Posts by User View Thanks

Alsterstreek		#166 Posted : 01 October 2017 01:20:35(UTC) Retweet
Joined: 16/11/2011(UTC) Posts: 5,753 Location: Hybrid Home		Today the breakthrough, a more sophisticated looking solution. I present Huevo depot, where Fanta Se and Grande lines merge to form the joint line to D’enfer (founded by French colonists), which is represented by the double track return blob (in the future mostly concealed). ATSF interchange to La Quinta is represented by the stub for the Mini Chief train, of course cutting recklessly through Grande tracks. The ascending line leads to Tennessee Williams Pass. The ceiling - 20 cm - of the underworld is ca. 1 cm below the loose end of high line. The styrofoam-soaked images cannot properly replicate the awesomeness of the appearance, but it is really looking good. :o) Oh yes, another test passed: Even the shorter inner blob track is holding the obligatory ABBA + 16 box cars (50 ft) + caboose. Track plan. Red = ascent to the upper world. Stub tracks still subject to change without prior notice. According to the track planner, there are considerable gaps, which I did not „feel“ when plugging together the ensemble. Further, according to the plan, dimensions are 101 x 211 cm, while I squeezed it effortlessly on a 100 x 200 cm surface. Edited by user 12 July 2018 11:57:23(UTC)  | Reason: typo
		Greetz - Ak My current "layout": https://www.marklin-user...aigne-Project#post592818
7 users liked this useful post by Alsterstreek		rbw993, CanadianKid, TrainIride, dennisb, kimballthurlow, baggio, Jimmy Thompson
User Profile View All Posts by User View Thanks

Alsterstreek		#167 Posted : 02 October 2017 08:56:58(UTC) Retweet
Joined: 16/11/2011(UTC) Posts: 5,753 Location: Hybrid Home		Train-room mush-room basement mock-up.
		Greetz - Ak My current "layout": https://www.marklin-user...aigne-Project#post592818
5 users liked this useful post by Alsterstreek		PJMärklin, TrainIride, hvc, kimballthurlow, Danlake
User Profile View All Posts by User View Thanks

Alsterstreek		#168 Posted : 20 October 2017 15:04:39(UTC) Retweet
Joined: 16/11/2011(UTC) Posts: 5,753 Location: Hybrid Home		Further to post 122. 163 x 163 cm (access bay 65 x 65 cm). Out and back operations - at least twice around - with train meet in between. Ruling grade 4.3%.
		Greetz - Ak My current "layout": https://www.marklin-user...aigne-Project#post592818
2 users liked this useful post by Alsterstreek		TrainIride, CanadianKid
User Profile View All Posts by User View Thanks

Alsterstreek		#169 Posted : 20 October 2017 21:06:52(UTC) Retweet
Joined: 16/11/2011(UTC) Posts: 5,753 Location: Hybrid Home		A forum member enquired if the design could be adapted to accommodate a Big Boy on a Walthers 130´(47 cm) turntable. I believe so. Siding length extended and stub terminal replaced by a concealed double track return blob. Still on 163 x 163 cm, but the access bay shrunk to 60 x 60 cm.
		Greetz - Ak My current "layout": https://www.marklin-user...aigne-Project#post592818
3 users liked this useful post by Alsterstreek		TrainIride, CanadianKid, grnwtrs
User Profile View All Posts by User View Thanks

Alsterstreek		#170 Posted : 05 November 2017 15:47:04(UTC) Retweet
Joined: 16/11/2011(UTC) Posts: 5,753 Location: Hybrid Home		Another way to conceal a dogbone end loop: http://www.edalon.net/mo...ellbahn-kehrschleife.htm
		Greetz - Ak My current "layout": https://www.marklin-user...aigne-Project#post592818
7 users liked this useful post by Alsterstreek		TrainIride, baggio, dennisb, Carim, CanadianKid, Danlake, petestra
User Profile View All Posts by User View Thanks

Alsterstreek		#171 Posted : 05 November 2017 16:02:15(UTC) Retweet
Joined: 16/11/2011(UTC) Posts: 5,753 Location: Hybrid Home		No circles or ovals involved here, but the mainline disappearing behind the tunnel portals could be curved. In addition, the first pair of crossovers to the right could be replaced by curved turnouts "swinging up left", thereby further reducing space requirements. Or the mainline could be connected to the reverse loop module like the one presented in the previous post, which would allow for turning and storing steam locomotives. This is a C track interpretation of the classic Minories concept by the late C. J. Freezer which was first published in 1957. The plan allows to model vibrant urban passenger (and express goods) traffic without requiring a great deal of space. Trains are hauled in by one locomotive that would then be uncoupled and remain caught until a fresh locomotive - having waited in the loco pocket - hauls away in the opposite direction. What I admire is how S-curves are avoided, thus ensuring nice swinging coach movements. https://en.wikipedia.org...Minories_(model_railway) Note: folded in half lengthwise using a removable girder road bridge to hide the hinges.
		Greetz - Ak My current "layout": https://www.marklin-user...aigne-Project#post592818
2 users liked this useful post by Alsterstreek		TrainIride, CanadianKid
User Profile View All Posts by User View Thanks

baggio		#172 Posted : 05 November 2017 17:27:37(UTC) Retweet
Joined: 21/09/2012(UTC) Posts: 1,730 Location: Toronto		Hi, Al: Very interesting topic and pictures. Could explain what the yellow bars in post 170 do? Thanks. Silvano
		Toronto Model Trains Fun Club
1 user liked this useful post by baggio		Alsterstreek
User Profile View All Posts by User View Thanks

Alsterstreek		#173 Posted : 05 November 2017 18:07:30(UTC) Retweet
Joined: 16/11/2011(UTC) Posts: 5,753 Location: Hybrid Home		Originally Posted by: baggio Could explain what the yellow bars in post 170 do? The author doesn´t say, but looking at a later blog photo (see attached), it seems as if they were placed in preparation of "filling" the tracks.
		Greetz - Ak My current "layout": https://www.marklin-user...aigne-Project#post592818
5 users liked this useful post by Alsterstreek		baggio, CanadianKid, kimballthurlow, grnwtrs, Danlake
User Profile View All Posts by User View Thanks

hvc		#174 Posted : 06 November 2017 10:23:48(UTC) Retweet
Joined: 03/06/2013(UTC) Posts: 431 Location: Melbourne, VIC, Australia		Originally Posted by: Alsterstreek Today the breakthrough, Alsterstreek, this is awesome. Love your work.
		- Herman
5 users liked this useful post by hvc		Alsterstreek, kimballthurlow, baggio, grnwtrs, Danlake
User Profile View All Posts by User View Thanks

Alsterstreek		#175 Posted : 07 November 2017 14:26:41(UTC) Retweet
Joined: 16/11/2011(UTC) Posts: 5,753 Location: Hybrid Home		Originally Posted by: hvc Originally Posted by: Alsterstreek Today the breakthrough Alsterstreek, this is awesome. Love your work. Thank you. The urban planning committee has decided to press forward with the project, which has been baptized "Hi-Land". Further progress to be reported under: https://www.marklin-user...d-and-Hi-Land#post554814
		Greetz - Ak My current "layout": https://www.marklin-user...aigne-Project#post592818
1 user liked this useful post by Alsterstreek		kimballthurlow
User Profile View All Posts by User View Thanks

Alsterstreek		#176 Posted : 25 November 2017 12:10:40(UTC) Retweet
Joined: 16/11/2011(UTC) Posts: 5,753 Location: Hybrid Home		Eric Miller´s circular GPM&C Ry in H0 scale. Track plan Mock-ups http://cs.trains.com/mrr...8631/2177191.aspx?page=5
		Greetz - Ak My current "layout": https://www.marklin-user...aigne-Project#post592818
5 users liked this useful post by Alsterstreek		kimballthurlow, Danlake, petestra, Jimmy Thompson, BR 05 002
User Profile View All Posts by User View Thanks

Alsterstreek		#177 Posted : 11 May 2018 15:04:57(UTC) Retweet
Joined: 16/11/2011(UTC) Posts: 5,753 Location: Hybrid Home		Another modeler, another scale, another idea. http://www.enndingen.de/Bahnalitaeten
		Greetz - Ak My current "layout": https://www.marklin-user...aigne-Project#post592818
6 users liked this useful post by Alsterstreek		kimballthurlow, Danlake, CanadianKid, hvc, petestra, BR 05 002
User Profile View All Posts by User View Thanks

Alsterstreek		#178 Posted : 15 May 2018 12:44:57(UTC) Retweet
Joined: 16/11/2011(UTC) Posts: 5,753 Location: Hybrid Home		Browsing through the gent's website I tried to understand the intricate N-scale track plan, which is a combination of dog bone courses. http://www.enndingen.de/.../ennderennsbruck2012.jpg The circles on the lower right hand side represent a triple helix. There seems to be a shadow station (covered by a visible station area?) connected to the lines pointing into the void....
		Greetz - Ak My current "layout": https://www.marklin-user...aigne-Project#post592818
1 user liked this useful post by Alsterstreek		petestra
User Profile View All Posts by User View Thanks

Alsterstreek		#179 Posted : 29 May 2018 12:45:23(UTC) Retweet
Joined: 16/11/2011(UTC) Posts: 5,753 Location: Hybrid Home		Another jewel - Canadian Canyons - short video : http://mrr.trains.com/la...adian-canyons-in-n-scale
		Greetz - Ak My current "layout": https://www.marklin-user...aigne-Project#post592818
3 users liked this useful post by Alsterstreek		Carim, NS1200, petestra
User Profile View All Posts by User View Thanks

Alsterstreek		#180 Posted : 28 June 2018 13:50:06(UTC) Retweet
Joined: 16/11/2011(UTC) Posts: 5,753 Location: Hybrid Home		Redux of the above on 2x7 ft door. http://cprailmmsub.blogs...hompson%20River%20Canyon
		Greetz - Ak My current "layout": https://www.marklin-user...aigne-Project#post592818
5 users liked this useful post by Alsterstreek		MalinAC, Carim, Danlake, petestra, TrainIride
User Profile View All Posts by User View Thanks

Alsterstreek		#181 Posted : 14 October 2018 21:19:22(UTC) Retweet
Joined: 16/11/2011(UTC) Posts: 5,753 Location: Hybrid Home		by Carl Robert Fallberg
		Greetz - Ak My current "layout": https://www.marklin-user...aigne-Project#post592818
1 user liked this useful post by Alsterstreek		Jimmy Thompson
User Profile View All Posts by User View Thanks

kiwiAlan		#182 Posted : 14 October 2018 22:02:04(UTC) Retweet
Joined: 23/07/2014(UTC) Posts: 8,211 Location: ENGLAND, Didcot		Originally Posted by: Alsterstreek You will use a lot of curved tracks with that one Alsterstreek
1 user liked this useful post by kiwiAlan		Alsterstreek
User Profile View All Posts by User View Thanks

Alsterstreek		#183 Posted : 06 December 2018 12:45:32(UTC) Retweet
Joined: 16/11/2011(UTC) Posts: 5,753 Location: Hybrid Home		Another contender to be considered in my view. Jim Griffin´s H0 scale DRGW La Plata Division layout: http://www.actionroad.ne...Division/LPD-Concept.htm And he even mirrors the actual Colorado Front Range situation. His concept of choosing an era to operate by running valid rolling stock for that period is quite interesting. Let alone his El Cheapo but artsy approach in regards to trackage, layout construction plus the semi-shelf out-and-back nolix-helix mix.
		Greetz - Ak My current "layout": https://www.marklin-user...aigne-Project#post592818
2 users liked this useful post by Alsterstreek		rbw993, Jimmy Thompson
User Profile View All Posts by User View Thanks

5HorizonsRR		#184 Posted : 06 December 2018 16:00:05(UTC) Retweet
Joined: 05/12/2004(UTC) Posts: 2,907 Location: CA, USA		I too am a big believer in building a layout where the era can be dictated by the rolling stock, not the rest of the layout. And with european locales it really isn't that difficult Some issues in cities, but thats about it. Of course it all depends how much you plan on superdetailing your layout. Since my other love is cars, I have no problem swapping out the 1/87 vehicles as well :)
		SBB Era 2-5
2 users liked this useful post by 5HorizonsRR		Alsterstreek, kimballthurlow
User Profile View All Posts by User View Thanks

Alsterstreek		#185 Posted : 21 March 2019 18:07:17(UTC) Retweet
Joined: 16/11/2011(UTC) Posts: 5,753 Location: Hybrid Home		The simple life? Single level, confusing crossings, multiple trains, limited space. https://model-railroad-hobbyist.com/node/32611
		Greetz - Ak My current "layout": https://www.marklin-user...aigne-Project#post592818
1 user liked this useful post by Alsterstreek		Jimmy Thompson
User Profile View All Posts by User View Thanks

Alsterstreek		#186 Posted : 21 March 2019 18:15:34(UTC) Retweet
Joined: 16/11/2011(UTC) Posts: 5,753 Location: Hybrid Home		Multi-level, running three trains simultaneously. http://www.modelscenerya...el-railroad-track-plans/
		Greetz - Ak My current "layout": https://www.marklin-user...aigne-Project#post592818
2 users liked this useful post by Alsterstreek		Jimmy Thompson, TEEWolf
User Profile View All Posts by User View Thanks

Alsterstreek		#187 Posted : 13 May 2019 16:52:31(UTC) Retweet
Joined: 16/11/2011(UTC) Posts: 5,753 Location: Hybrid Home		I'd like to cross-reference my below 2015 post here, since it was sitting in a dead thread while well fitting into the concept of ovals and circles. Originally Posted by: Alsterstreek Originally Posted by: sedgar2 What are people using as an acceptable grade, that keeprealism and keeps a loaded power unit from spinning wheels. Well, depends, as everything in life. As Ray pointed out up to 5% operations run well. Curved ramps cause more friction than straight ones, S-curves are worse than continuous curves. Another factor is train length (and consequently weight to be pulled). Then, a train moving over a 5% grade looks more acceptable than one sitting on one. My experience is that 3% is the minimum for aesthetics; and with 3% there are no limits when it comes to climbing ability. Caveat: I experienced derailing on a (tunneled) 3% grade on a tight R1 radius stretch for heavy tin plate goods trains with more than 100 axles or passenger trains more than 8 coaches only. ;o) Originally Posted by: sedgar2 What are the procedured to keep the tracks from separating? C-track: none. Originally Posted by: sedgar2 Any photos? See below. Various C-track set-ups, all ramps curved, radius used in green fonts, grade in red fonts.
		Greetz - Ak My current "layout": https://www.marklin-user...aigne-Project#post592818
3 users liked this useful post by Alsterstreek		Jimmy Thompson, TEEWolf, kimballthurlow
User Profile View All Posts by User View Thanks

Alsterstreek		#188 Posted : 03 September 2019 11:09:14(UTC) Retweet
Joined: 16/11/2011(UTC) Posts: 5,753 Location: Hybrid Home		A track plan by Clive Lamming: I once gave the links here: https://www.marklin-user...ench-Layout-s#post377182
		Greetz - Ak My current "layout": https://www.marklin-user...aigne-Project#post592818
4 users liked this useful post by Alsterstreek		Jimmy Thompson, Carim, 5HorizonsRR, kimballthurlow
User Profile View All Posts by User View Thanks

Alsterstreek		#189 Posted : 03 September 2019 11:19:15(UTC) Retweet
Joined: 16/11/2011(UTC) Posts: 5,753 Location: Hybrid Home		Some ideas from a French blog. http://papybricolo.over-blog.com
		Greetz - Ak My current "layout": https://www.marklin-user...aigne-Project#post592818
2 users liked this useful post by Alsterstreek		Jimmy Thompson, Carim
User Profile View All Posts by User View Thanks

Alsterstreek		#190 Posted : 03 November 2019 23:42:15(UTC) Retweet
Joined: 16/11/2011(UTC) Posts: 5,753 Location: Hybrid Home		Inspired by the winding Maryland and Pennsylvania Railroad, fondly remembered as the “Ma and Pa”.
		Greetz - Ak My current "layout": https://www.marklin-user...aigne-Project#post592818
1 user liked this useful post by Alsterstreek		Jimmy Thompson
User Profile View All Posts by User View Thanks

Alsterstreek		#191 Posted : 20 November 2019 13:16:56(UTC) Retweet
Joined: 16/11/2011(UTC) Posts: 5,753 Location: Hybrid Home		I do not remember if I posted this already earlier: A compact bi-level design allowing to turn trains into either direction. The lower "distribution" level is mostly concealed except for the short "Parade-Strecke" in front, while the upper level offers yard action. Depending on one´s tolerance regarding minimum radius and maximum ramp inclination (and minimum passing track length), this could be squeezed onto a 85 x 180 cm surface.
		Greetz - Ak My current "layout": https://www.marklin-user...aigne-Project#post592818
1 user liked this useful post by Alsterstreek		Jimmy Thompson
User Profile View All Posts by User View Thanks

Alsterstreek		#192 Posted : 20 November 2019 15:35:06(UTC) Retweet
Joined: 16/11/2011(UTC) Posts: 5,753 Location: Hybrid Home		N scale oval.
		Greetz - Ak My current "layout": https://www.marklin-user...aigne-Project#post592818
1 user liked this useful post by Alsterstreek		Jimmy Thompson
User Profile View All Posts by User View Thanks

Alsterstreek		#193 Posted : 05 April 2020 18:06:26(UTC) Retweet
Joined: 16/11/2011(UTC) Posts: 5,753 Location: Hybrid Home		Compact Märklin H0 M-track retro style layout “Stadtbahnhof Hafentor“ under construction by a German gent:
		Greetz - Ak My current "layout": https://www.marklin-user...aigne-Project#post592818
2 users liked this useful post by Alsterstreek		Jimmy Thompson, hvc
User Profile View All Posts by User View Thanks

5HorizonsRR		#194 Posted : 05 April 2020 18:36:01(UTC) Retweet
Joined: 05/12/2004(UTC) Posts: 2,907 Location: CA, USA		Originally Posted by: Alsterstreek A track plan by Clive Lamming: I once gave the links here: https://www.marklin-user...ench-Layout-s#post377182 What a fantastic little plan! Tons of action in a small space, and leads to organically extend it for those who are inclined.
		SBB Era 2-5
1 user liked this useful post by 5HorizonsRR		Alsterstreek
User Profile View All Posts by User View Thanks

Alsterstreek		#195 Posted : 09 April 2020 15:21:38(UTC) Retweet
Joined: 16/11/2011(UTC) Posts: 5,753 Location: Hybrid Home		The X Factor, a staging approach presented in the MR magazine in 2004.
		Greetz - Ak My current "layout": https://www.marklin-user...aigne-Project#post592818
2 users liked this useful post by Alsterstreek		rbw993, Jimmy Thompson
User Profile View All Posts by User View Thanks

Alsterstreek		#196 Posted : 12 April 2020 15:58:50(UTC) Retweet
Joined: 16/11/2011(UTC) Posts: 5,753 Location: Hybrid Home		A practical approach incorporating the aforementioned X Factor staging. Source: Realistic Model Railroad Design: Your Step-By-Step Guide to Creating a Unique Operating Layout, Tony Koester, 2004
		Greetz - Ak My current "layout": https://www.marklin-user...aigne-Project#post592818
3 users liked this useful post by Alsterstreek		Bogenschütze, kimballthurlow, Jimmy Thompson
User Profile View All Posts by User View Thanks

rbw993		#197 Posted : 13 April 2020 20:43:09(UTC) Retweet
Joined: 19/08/2008(UTC) Posts: 970		Here is a variation with a way to avoid fouling "Desmaigne" and/or keep the exit/entry junction in view, a connecting track (blue line). I think I saw something like this in Amstrong's book. Roger
2 users liked this useful post by rbw993		Alsterstreek, Jimmy Thompson
User Profile View All Posts by User View Thanks

Alsterstreek		#198 Posted : 13 April 2020 22:37:09(UTC) Retweet
Joined: 16/11/2011(UTC) Posts: 5,753 Location: Hybrid Home		Thou shalt not foul Desmaigne ! :o)
		Greetz - Ak My current "layout": https://www.marklin-user...aigne-Project#post592818
2 users liked this useful post by Alsterstreek		rbw993, Jimmy Thompson
User Profile View All Posts by User View Thanks

Alsterstreek		#199 Posted : 24 May 2020 15:17:11(UTC) Retweet
Joined: 16/11/2011(UTC) Posts: 5,753 Location: Hybrid Home		Just playing around. I was thinking about allowing a „frontal“ view into a gorge and yard space "around the corner", a non-fiddle yard so to speak. Out came a 210 x 240 cm (outer dimensions) L-shape. The L- shape is good for gaining height, while offering pleasant views. Grades are between 2% and 3%. Although visually separated, the yard looks a little bit too dominant for my taste. However, it is just a study.
		Greetz - Ak My current "layout": https://www.marklin-user...aigne-Project#post592818
3 users liked this useful post by Alsterstreek		hvc, Jimmy Thompson, Legless
User Profile View All Posts by User View Thanks

5HorizonsRR		#200 Posted : 24 May 2020 17:47:08(UTC) Retweet
Joined: 05/12/2004(UTC) Posts: 2,907 Location: CA, USA		I love it, but agreed it is a lot of yard! Perhaps behind the divider make an urban scene above the bulk of the yard, and leave the front 2-3 tracks exposed? (125th st tunnel in New York city comes to mind...)
		SBB Era 2-5
1 user liked this useful post by 5HorizonsRR		Alsterstreek
User Profile View All Posts by User View Thanks

Users browsing this topic

Guest (2)

6 Pages«<23456> Go to Page...
