Offline revmox
#1 Posted : 05 July 2022 04:38:29(UTC)
revmox

Australia
Joined: 26/05/2021(UTC)
Posts: 148
Location: Australia, East Maitland, NSW
What is the recommended way to get multiple electrical connections between rolling stock? I see there are current carrying couplers for simple connections but what if you want 4 or 6 connections?

I've found a way to get a few wires across but the solution has many issues, particularly fixed coupling. There must be a better way.

This is what I tried for those who might be interested.

First - slung under a 3D printed drawbar. Can get two 1.0mm wires across or up to twelve tiny decoder wires.


Second - through the centre of the drawbar. Can get one 1.0mm wire or 4 decoder wires easy - 6 decoder wires with much patience and some swearing.

V4 - 1.jpgPXL_20220704_223437741.jpgPXL_20220704_230818815.jpgPXL_20220704_231007197.MP.jpg

thanks 6 users liked this useful post by revmox
Offline costing
#2 Posted : 06 July 2022 20:15:28(UTC)
costing

Switzerland
Joined: 20/08/2018(UTC)
Posts: 157
Location: Geneve, Geneva
Kudos for the coupler design, that will clearly be useful.

For more flexibility I went with ESU's couplers, for a two-wire connection: https://www.esu.eu/en/pr...urrent-carrying-coupler/
JMRI on RPi & DCC++ / C-track / Marklin, Roco, ESU, Bemo locos / Christmas car collector
