Hi,

A friend asked for an interior for the 4018 railbus trailer, so I made one. The 3016 railbus is filled with the motor and the reversing unit, but the trailer has lot of space inside.
The part fits into the railbus without any modification. Only the windows should be relaced with a clear foil, otherwise nobody will see it. I fitted no windows for the picture to have a better photo-quality.

I ignored the toilet. The walls of the toilet would block the light from the bulb. So I decided to draw it without a toilet.


UserPostedImage

UserPostedImage

UserPostedImage

The file:
https://www.thingiverse.com/thing:2779925

Regards

Markus
thanks 24 users liked this useful post by Markus Schild
Offline AmalfiCoast
#2 Posted : 02 February 2018 22:05:25(UTC)
AmalfiCoast

United States
Joined: 04/11/2016(UTC)
Posts: 153
Location: Maryland, South Laurel
Looks good. Great job!
Offline river6109
#3 Posted : 02 February 2018 22:43:18(UTC)
river6109

Australia
Joined: 22/01/2009(UTC)
Posts: 14,636
Location: On 1965 Märklin Boulevard just around from Roco Square
Its another job for the butcher, to cut the legs off from the Preisler figures.Crying
https://www.youtube.com/river6109
https://www.youtube.com/6109river
5 years in Destruction mode
50 years in Repairing mode
Offline kiwiAlan
#4 Posted : 02 February 2018 23:43:30(UTC)
kiwiAlan

United Kingdom
Joined: 23/07/2014(UTC)
Posts: 8,082
Location: ENGLAND, Didcot
Originally Posted by: river6109 Go to Quoted Post
Its another job for the butcher, to cut the legs off from the Preisler figures.Crying


They do have some pre-butchered ones if you feel that sqeamish BigGrin BigGrin BigGrin

Offline DaleSchultz
#5 Posted : 03 February 2018 04:03:25(UTC)
DaleSchultz

United States
Joined: 10/02/2006(UTC)
Posts: 3,997
great job!
Dale
Intellibox + own software, K-Track
My current layout: https://cabin-layout.mixmox.com
Arrival and Departure signs: https://remotesign.mixmox.com
Offline jvuye
#6 Posted : 03 February 2018 21:53:27(UTC)
jvuye

Belgium
Joined: 01/03/2008(UTC)
Posts: 2,881
Location: South Western France
Excellent Markus!
You're becoming the expert in 3D printing...and you certainly have awakened my interest!
Cheers
Jacques
Jacques Vuye aka Dr.Eisenbahn
Once a vandal, learned to be better and had great success!
Offline hennabm
#7 Posted : 04 February 2018 11:23:52(UTC)
hennabm

Scotland
Joined: 22/09/2009(UTC)
Posts: 2,040
Location: Edinburgh,
Excellent job.ThumpUp

Where do we form the queue to purchase oneLove

Mike
1957 - 1985 era
What's digital?
Offline Francois29
#8 Posted : 04 February 2018 11:31:48(UTC)
Francois29

France
Joined: 01/05/2014(UTC)
Posts: 64
Location: BRITTANY
Good idea ! I am interested !
Offline Markus Schild
#9 Posted : 04 February 2018 16:12:33(UTC)
Markus Schild

Germany
Joined: 14/01/2006(UTC)
Posts: 1,802
Location: Wurttemberg
Originally Posted by: hennabm Go to Quoted Post
Excellent job.ThumpUp

Where do we form the queue to purchase oneLove

Mike


Hi,

Thank you all for the compliments.

My capacities are limited and every part takes about three hours to print in the quality shown. If you don't know anybody to else to ask to print the part, I can also do it, but only in limited quantities. The price here will be around 5 EUR +Postage. If you are interested, write me a private mail.

Regards

Markus

Edited by user 04 February 2018 19:52:57(UTC)  | Reason: time corrected

thanks 1 user liked this useful post by Markus Schild
Offline Br502362
#10 Posted : 06 February 2018 14:08:47(UTC)
Br502362

Finland
Joined: 05/03/2014(UTC)
Posts: 680
Location: Finland
Hi Markus,

Have you thought about printing Märklin 0222, 0223, 0224 and 0225 interior kits?


Regards

Åke
thanks 1 user liked this useful post by Br502362
Offline GlennM
#11 Posted : 06 February 2018 15:17:05(UTC)
GlennM

United Kingdom
Joined: 09/05/2011(UTC)
Posts: 2,877
Location: Somewhere, But Nowhere Near Manchester, England
Looks great Markus ThumpUp ThumpUp ThumpUp
Don't look back, your not heading that way.
Offline Markus Schild
#12 Posted : 06 February 2018 17:14:17(UTC)
Markus Schild

Germany
Joined: 14/01/2006(UTC)
Posts: 1,802
Location: Wurttemberg
Originally Posted by: Br502362 Go to Quoted Post
Hi Markus,

Have you thought about printing Märklin 0222, 0223, 0224 and 0225 interior kits?




Hi Åke,

I put it on the list. But next will be the UMBAUWAGEN 4067, 4079 and 4090.

Regards

Markus

thanks 1 user liked this useful post by Markus Schild
Offline siroljuk
#13 Posted : 08 February 2018 15:17:57(UTC)
siroljuk

Finland
Joined: 29/10/2010(UTC)
Posts: 377
HelloBigGrin

I did print also this interior piece. I have Prusa 3i printer and I use ultimaker Cura-slicer. I had difficulty removing support structures though.

One question for Marcus: From your pictures I can see that you have managed very well removing support structures.

Can you tell us any detail about support configure of your printer for this thing.

I have done quite much different small parts for my layout and for oldest rolling stockBigGrin BigGrin
3D-printing is fun and not so expensive any more.
Regards

Jukka
Offline Markus Schild
#14 Posted : 08 February 2018 16:13:51(UTC)
Markus Schild

Germany
Joined: 14/01/2006(UTC)
Posts: 1,802
Location: Wurttemberg
Hi Jukka,

Which version of CURA do you use? Versions below 3.0 don't do it well. I set the "Support Placement" to "Touching Buildspace" only.
So, where you don't see any support-structures, there aren't any. This is how the part comes out of the printer:

UserPostedImage

UserPostedImage

Regards

Markus
thanks 2 users liked this useful post by Markus Schild
Offline siroljuk
#15 Posted : 09 February 2018 08:00:29(UTC)
siroljuk

Finland
Joined: 29/10/2010(UTC)
Posts: 377
Thanks for your answer.BigGrin

CURA 2.7 was the version I did use. Now I have latest version and try again.

IMHO most difficult thing in 3D printing is to find good design program which is free and easy to learn. Based on my own experiences AutoCad is good but expensive and it take much time to learn. Tinkecad is simple and free but it takes much imagination to create complicated and precise pieces.

I would like to know which programs people use and are satisfied.Blushing Blushing

Regards

Jukka
Offline kiwiAlan
#16 Posted : 09 February 2018 17:16:34(UTC)
kiwiAlan

United Kingdom
Joined: 23/07/2014(UTC)
Posts: 8,082
Location: ENGLAND, Didcot
Originally Posted by: siroljuk Go to Quoted Post

I would like to know which programs people use and are satisfied.Blushing Blushing

Regards

Jukka


+1 ThumpUp
Offline Markus Schild
#17 Posted : 09 February 2018 17:30:27(UTC)
Markus Schild

Germany
Joined: 14/01/2006(UTC)
Posts: 1,802
Location: Wurttemberg
Hi,

I use FreeCAD. But I think about moving to FUSION360. I'm not really satisfied with FreeCAD, but I know how to use it. Complex FreeCAD models like to become corrupt and sometimes you really get bad surprises. But as long as it works, it's a fine program. The models published here are all made with FreeCAD.

Regards

Markus
thanks 1 user liked this useful post by Markus Schild
Offline Jvdwaa
#18 Posted : 22 April 2019 18:47:46(UTC)
Jvdwaa

Netherlands
Joined: 04/04/2017(UTC)
Posts: 17
Great design for the 4018, downloaded it and will print it for sure!
I made a similar design for the "Silberlingen", see https://www.thingiverse.com/search?q=jvdwaa
thanks 3 users liked this useful post by Jvdwaa
