adding telex coupler - I want to add a telex coupler to my SBB E3/3

Options

View

Previous Topic Next Topic

Timnomads		#1 Posted : 23 February 2016 11:33:17(UTC) Retweet
Joined: 16/09/2015(UTC) Posts: 290 Location: Grandvaux - Lausanne - Switzerland		Hi All I have an SBB E3/3 shunter 36330 I want to try and add a telex coupler I found on Ebay, and hopefully control uncoupling through my CS2 I am not an expert with marklin digital but would this be possible with my older digital shunter ? If the soldering is easy as it is my first attempt, I would like to give it a try. Thanks in advance Tim

1 user liked this useful post by Timnomads		Alsterstreek
User Profile View All Posts by User View Thanks


	Wish to join the discussion?! Login to your marklin-users.net community \| Forum account or Register a new forum account. Or Connect via Facebook

H0		#2 Posted : 23 February 2016 13:43:40(UTC) Retweet
Joined: 16/02/2004(UTC) Posts: 15,262 Location: DE-NW		Hi, Tim! Originally Posted by: Timnomads If the soldering is easy as it is my first attempt, I would like to give it a try. I don't have this loco. You will probably need a new decoder. And you will have to find solder pads for AUX1 and AUX2 and Plus. The loco probably has an ESU decoder, maybe with a NEM 652 plug. It could be difficult to find room for the Telex cables. Did you ever open your loco?
		Regards Tom --- "In all of the gauges, we particularly emphasize a high level of quality, the best possible fidelity to the prototype, and absolute precision. You will see that in all of our products." (from Märklin New Items Brochure 2015, page 1) ROFLBTCUTS


User Profile View All Posts by User View Thanks

Timnomads		#3 Posted : 23 February 2016 13:46:08(UTC) Retweet
Joined: 16/09/2015(UTC) Posts: 290 Location: Grandvaux - Lausanne - Switzerland		Originally Posted by: H0 Hi, Tim! Originally Posted by: Timnomads If the soldering is easy as it is my first attempt, I would like to give it a try. I don't have this loco. You will probably need a new decoder. And you will have to find solder pads for AUX1 and AUX2 and Plus. The loco probably has an ESU decoder, maybe with a NEM 652 plug. It could be difficult to find room for the Telex cables. Did you ever open your loco? No I did not, I will have look at the weekend and take aphoto of what i find Tim


User Profile View All Posts by User View Thanks

river6109		#4 Posted : 23 February 2016 13:59:12(UTC) Retweet
Joined: 22/01/2009(UTC) Posts: 14,712 Location: On 1965 Märklin Boulevard just around from Roco Square		Tim, there is nothing wrong with trying, and my motto is: there is a way , the only thing you have to do is find it,, by using an ESU decoder you can add 2 telex coupling under Aux 1 and Aux 2, it would be nice if you have a lokprogrammer and it is very easy to program the pulse time and with Version 4 lokpilots you have other options it actually pushes the carriage a bit forward, I personally would recommend it and hopefully you can find a way. if not as many photos from the front and rear coupling outside and inside and I should be able to assist you if you need help. I've added telex coupling to a E BR 63/163 and they only had coupling hooks John
		https://www.youtube.com/river6109 https://www.youtube.com/6109river 5 years in Destruction mode 50 years in Repairing mode
		WWW

User Profile View All Posts by User View Thanks

biedmatt		#5 Posted : 23 February 2016 14:09:15(UTC) Retweet
Joined: 09/04/2012(UTC) Posts: 1,343 Location: Southwest Ohio		Hi Tim, This could be impossible. As Tom states, you will need a new decoder. The old FX can't be reconfigured, so you can't add functions that were not there from the beginning. Physically, from the exploded diagram, it looks like it may be impossible. The FX decoder fits around the motor and drive gears, optimizing space. A new decoder, even an ESU with leads attached (no adapter board) may not fit. Perhaps there is room between the motor and the body housing. I wish you luck. https://medienpdb.maerkl...es/1/pdf/36330_explo.pdf
		Matt Era 3 DB lokos, coaches and freight cars from across Europe But I do have the obligatory (six) SBB Krocs ECoS 50200, all FX and MFX decoders replaced with ESU V4s, operated in DCC-RailCom+ with ABC brake control. With the exception of the passenger wagens with Marklin current conducting couplers, all close couplers have been replaced with Roco 40397.


User Profile View All Posts by User View Thanks

Timnomads		#6 Posted : 24 February 2016 09:08:18(UTC) Retweet
Joined: 16/09/2015(UTC) Posts: 290 Location: Grandvaux - Lausanne - Switzerland		Hi All I had a look inside the loco and I do not think I have enough space. So I will have to buy another shunting loco, interestingly the latest Marklin SBB offering the two half shoes 36332 They do not have telex couplers, why not ???? Tim


User Profile View All Posts by User View Thanks

RayF		#7 Posted : 24 February 2016 10:56:20(UTC) Retweet
Joined: 14/03/2005(UTC) Posts: 15,839 Location: Gibraltar, Europe		Maybe they were trying to keep the price down - they are already very expensive!
		Ray Mostly Marklin.Selection of different eras and European railways Small C track layout, control by MS2, 100+ trains but run 4-5 at a time.


User Profile View All Posts by User View Thanks

river6109		#8 Posted : 24 February 2016 14:21:39(UTC) Retweet
Joined: 22/01/2009(UTC) Posts: 14,712 Location: On 1965 Märklin Boulevard just around from Roco Square		Tim, why don't you take th housing off and let me see what room there is available. an ESU decoder should fit into the space what ever was there before John
		https://www.youtube.com/river6109 https://www.youtube.com/6109river 5 years in Destruction mode 50 years in Repairing mode
		WWW

User Profile View All Posts by User View Thanks

Ross		#9 Posted : 24 February 2016 21:06:33(UTC) Retweet
Joined: 25/09/2006(UTC) Posts: 872 Location: Sydney, NSW		Hello Tim/All, This is how I did a Telex upgrade to the 36331 loco which I'm sure will give you a few ideas. http://members.ozemail.com.au/~...lokpilot_36331_telex.pdf Originally Posted by: Timnomads Hi All I have an SBB E3/3 shunter 36330 I want to try and add a telex coupler I found on Ebay, and hopefully control uncoupling through my CS2 I am not an expert with marklin digital but would this be possible with my older digital shunter ? If the soldering is easy as it is my first attempt, I would like to give it a try. Thanks in advance Tim
		Ross
		WWW
5 users liked this useful post by Ross		BrandonVA, RayF, biedmatt, Moritz-BR365, 3rail4life
User Profile View All Posts by User View Thanks

Timnomads		#10 Posted : 25 February 2016 14:30:56(UTC) Retweet
Joined: 16/09/2015(UTC) Posts: 290 Location: Grandvaux - Lausanne - Switzerland		Originally Posted by: Ross Hello Tim/All, This is how I did a Telex upgrade to the 36331 loco which I'm sure will give you a few ideas. http://members.ozemail.com.au/~...lokpilot_36331_telex.pdf Hi Ross Sounds as though its just what I need but I can't get the link to work for the PDF, can you try and attach it to the thread as an attached file please. Thanks Tim Originally Posted by: Timnomads Hi All I have an SBB E3/3 shunter 36330 I want to try and add a telex coupler I found on Ebay, and hopefully control uncoupling through my CS2 I am not an expert with marklin digital but would this be possible with my older digital shunter ? If the soldering is easy as it is my first attempt, I would like to give it a try. Thanks in advance Tim


User Profile View All Posts by User View Thanks

Ross		#11 Posted : 25 February 2016 22:39:05(UTC) Retweet
Joined: 25/09/2006(UTC) Posts: 872 Location: Sydney, NSW		Hi Tim, I'm not sure why the link isn't working for you as it works for me ok. If you can't use the link just visit my web pages and under TIPs you will find the file. Originally Posted by: Timnomads Originally Posted by: Ross Hello Tim/All, Hi Ross Sounds as though its just what I need but I can't get the link to work for the PDF, can you try and attach it to the thread as an attached file please. Thanks Tim
		Ross
		WWW

User Profile View All Posts by User View Thanks
