Smoke units and there use
Share
Options
View
Go to last post in this topic Go to first unread post in this topic
Previous Topic Next Topic
Offline danmarklinman
#1 Posted : 27 December 2017 23:15:25(UTC)
Retweet
danmarklinman

United Kingdom
Joined: 18/10/2012(UTC)
Posts: 1,379
Dear all, How much oil do I put in, when I fill the smoke unit up? As I don’t want to brake the oil burner. Also. Should I only use Marklin smoke oil for the unit, 72270 Or Can I use other smoke oils, designed to smell like real steam locomotives for instance?
Marklin and Piko era 4 SNCB , Marklin wagons
Wiking model car Fan
Faller fan including car system
Instagram: marklin1978
Wiking fan
Back to top

Wish to join the discussion?! Login to your marklin-users.net community | Forum accountor Register a new forum account. Or Connect via Facebook
Back to top
Offline H0
#2 Posted : 28 December 2017 08:51:19(UTC)
Retweet
H0


Joined: 16/02/2004(UTC)
Posts: 15,272
Location: DE-NW
Hi!
Originally Posted by: danmarklinman Go to Quoted Post
How much oil do I put in, when I fill the smoke unit up?
I follow instructions from the manufacturer and fill 0.2 ml from a syringe. It's up to you how much you fill in ...
... but with too much fluid you get no smoke.
The reseller writes "6 drops", but I only find that confusing. Buy from the manufacturer and you get a suitable syringe with the smoke generator.

Originally Posted by: danmarklinman Go to Quoted Post
Should I only use Marklin smoke oil for the unit, 72270
Märklin are just a reseller for the Seuthe fluid. Compare prices for Seuthe fluid and Märklin fluid and get the cheaper one.
I haven't tried other fluids in Seuthe smoke generators. Reports say that SR24 works fine, but I don't wanna take any risk with my smoke generators.
Regards
Tom
---
"In all of the gauges, we particularly emphasize a high level of quality, the best possible fidelity to the prototype, and absolute precision. You will see that in all of our products." (from Märklin New Items Brochure 2015, page 1) ROFLBTCUTS
UserPostedImage
Back to top
thanks 1 user liked this useful post by H0
Offline danmarklinman
#3 Posted : 28 December 2017 09:30:13(UTC)
Retweet
danmarklinman

United Kingdom
Joined: 18/10/2012(UTC)
Posts: 1,379
Hi, I didn’t get a syringe with my smoke generator kitCrying or instructions? Just a hazard notice. It was new from Modellbahn Kramm who’s service has dropped, I think.
Thanks for your help on the oils. My local model shop sells smoke oil that smells like steam smoke. I will see what make it is.
Marklin and Piko era 4 SNCB , Marklin wagons
Wiking model car Fan
Faller fan including car system
Instagram: marklin1978
Wiking fan
Back to top
Offline H0
#4 Posted : 28 December 2017 09:52:35(UTC)
Retweet
H0


Joined: 16/02/2004(UTC)
Posts: 15,272
Location: DE-NW
Originally Posted by: danmarklinman Go to Quoted Post
Hi, I didn’t get a syringe with my smoke generator kitCrying
That's the problem when you buy Seuthe smoke generators in a Märklin box: the most useful accessories are missing and the instructions make no sense.
Buy a smoke generator in a Seuthe bag and you will have a useful syringe.

Regards
Tom
---
"In all of the gauges, we particularly emphasize a high level of quality, the best possible fidelity to the prototype, and absolute precision. You will see that in all of our products." (from Märklin New Items Brochure 2015, page 1) ROFLBTCUTS
UserPostedImage
Back to top
thanks 1 user liked this useful post by H0
Offline Br502362
#5 Posted : 28 December 2017 12:00:50(UTC)
Retweet
Br502362

Finland
Joined: 05/03/2014(UTC)
Posts: 683
Location: Finland
Hi,

4-6 drops is ok. Also SR24 works fine, but the smell is different.
Seuthe/Märklin smoke oil has the "right" smell which brings childhood to your mind Woot

Cheers
Åke
Back to top
Offline analogmike
#6 Posted : 28 December 2017 13:36:00(UTC)
Retweet
analogmike

United States
Joined: 02/08/2014(UTC)
Posts: 742
Location: NEW JERSEY, USA
Hi Dan,
I have been using this stuff for 20-30 years. It never went stale and the smell is just like the old Marklin fluid.
Take a trip down to the local pharmacy and get a regular eye dropper 7-8 drops are fine.
Mikey

smoke fluid 001.JPG
I love the smell of smoke fluid in the morning .
Back to top
thanks 2 users liked this useful post by analogmike
Offline danmarklinman
#7 Posted : 28 December 2017 14:32:29(UTC)
Retweet
danmarklinman

United Kingdom
Joined: 18/10/2012(UTC)
Posts: 1,379


Well it makes a good head of steamLOL Love
Marklin and Piko era 4 SNCB , Marklin wagons
Wiking model car Fan
Faller fan including car system
Instagram: marklin1978
Wiking fan
Back to top
Offline kiwiAlan
#8 Posted : 28 December 2017 19:30:30(UTC)
Retweet
kiwiAlan

United Kingdom
Joined: 23/07/2014(UTC)
Posts: 8,111
Location: ENGLAND, Didcot
I suspect the LGB smoke oil is also repackaged Seuthe oil.

I have also heard that musicians valve oil (as used on the valves on trumpets and similar instruments) also makes good smoke oil.

Another possibility is the ESU smoke oil, which I beleive is different to the Seuthe oil, and has to be used in the smoke units of ESU locos, but is also OK in Seuthe smoke units.
Back to top
thanks 2 users liked this useful post by kiwiAlan
Offline Crazy Harry
#9 Posted : 29 December 2017 04:03:12(UTC)
Retweet
Crazy Harry

Canada
Joined: 18/11/2008(UTC)
Posts: 477
Location: Oakville, Ontario
I recently purchased some Marklin smoke fluid. The first thing I noticed, it is no longer lemon scented. When did they change that? (I think I'm dating myself with that question!)

Cheers,

Harold.
Back to top
Offline Minok
#10 Posted : 29 December 2017 06:30:19(UTC)
Retweet
Minok

United States
Joined: 15/10/2006(UTC)
Posts: 2,311
Location: Washington, Pacific Northwest
I'd use the fluid recommended by the smoke unit manufacturer and not mix and match as the cook off temp of the fluid needs to match the smoke units heating characteristics. I picked up the Märklin unit (a Seuth unit) along wit a bigger bottle of fluid and then got a dropper dropper pippett that any model shop of drug store sells.

Just a handful of drops is enough to fill the smoker as they don't have a lot of room. Overfilled or with air trapped they don't smoke, which can be fixed.
Toys of tin and wood rule!
---
My Layout Thread on marklin-users.net: InterCity 1-3-4
My YouTube Channel:
https://youtube.com/@intercity134
Back to top
thanks 1 user liked this useful post by Minok
Offline JohnjeanB
#11 Posted : 29 December 2017 10:44:20(UTC)
Retweet
JohnjeanB

France
Joined: 04/02/2011(UTC)
Posts: 3,145
Location: Paris, France
Hi All,

I use a serynge and fill the Seuthe smoke generator and then putting the tip of the needle 8 to 10 mm inside it, I get back the liquid until air is coming un the syringe.
Any used small serynge will do.
Now I use fluid less and less as it covers my locos with oily splashes and it cuts out very rapidly.
Seuthe smoke tubes have 2 ends; one with 90° angle cut and the second with a 45° angle cut. When the first end is down, smoke production is smaller but lasts longer
Happy new year

Jean
My layout videos
latest vid
marshalling yard
My Layout
Back to top
Offline carlos.rivas.16752
#12 Posted : 29 December 2017 15:46:43(UTC)
Retweet
carlos.rivas.16752

Spain
Joined: 08/04/2015(UTC)
Posts: 303
Location: Vigo, Spain
I´m using the Wiesmann fluid and it works fine with Seuthe generators.

Happy new year
Carlos
My blog both in Spanish and English: https://grunewiesen1965.wordpress.com
Back to top
BLOG
Offline H0
#13 Posted : 29 December 2017 15:56:42(UTC)
Retweet
H0


Joined: 16/02/2004(UTC)
Posts: 15,272
Location: DE-NW
Originally Posted by: carlos.rivas.16752 Go to Quoted Post
I´m using the Wiesmann fluid and it works fine with Seuthe generators.
Judging from their product descriptions I bet that Viessmann/Vollmer are just reselling Seuthe smoke generators and smoke fluid.
Regards
Tom
---
"In all of the gauges, we particularly emphasize a high level of quality, the best possible fidelity to the prototype, and absolute precision. You will see that in all of our products." (from Märklin New Items Brochure 2015, page 1) ROFLBTCUTS
UserPostedImage
Back to top
