Offline SteamNut
#1 Posted : 16 May 2015 18:18:15(UTC)

United States
Joined: 11/05/2013(UTC)
Posts: 488
Thanks to Alan Rees and Alan from Frankfurt this was posted in Railway of Germany Form. The true nature of the studs (projections) are not known perhaps they hold the ties from shifting, or as one member remarked, Marklin pulled off a promotional stunt - Fred
SteamNut attached the following image(s):
Marklin Track.jpg
thanks 14 users liked this useful post by SteamNut
Offline Webmaster
#2 Posted : 16 May 2015 18:30:09(UTC)

Joined: 25/07/2001(UTC)
Posts: 11,154
Perfect, now we know the Märklin track is prototypical too... BigGrin
M, K & C tracks are ok - at least with a German layout theme...

As you say, probably to secure the ties on the banked roadbed.
Juhan - "Webmaster", at your service...
He who asks a question is a fool for five minutes. He who does not ask a question remains a fool forever. [Old Chinese Proverb]
thanks 3 users liked this useful post by Webmaster
Offline xxup
#3 Posted : 16 May 2015 23:29:31(UTC)

Joined: 15/03/2003(UTC)
Posts: 9,348
Location: Australia
It's a photoshop job.. Laugh Zoom in and have a closer look.
Australia flag by abFlags.com
thanks 3 users liked this useful post by xxup
Offline Tdl
#4 Posted : 20 May 2015 15:45:10(UTC)

Joined: 30/03/2006(UTC)
Posts: 71
Location: Amsterdam

here is my proposal for a new marklin track: concrete sleepers and rail clips.


The studs are actually anchoring the track to the roadbed. This is sometimes done in curves.
Notice the sleepers. Two types are used.

I have found this picture on the internet a couple of years ago.
It was taken in Germany by someone else, I do not recall the location.

It would be nice when marklin will start to offer track and points with concrete sleepers en clip connections imitation.

Regards, Willem

thanks 8 users liked this useful post by Tdl
Offline Tom Jessop
#5 Posted : 27 May 2015 23:18:36(UTC)
Tom Jessop

Joined: 14/12/2002(UTC)
Posts: 796
Location: Newcastle NSW Australia

A similar fixing style is used on most rail networks , usually on curves where the track can move sideways when a train travels over it but I have seen a fair bit of use on points for the same problem . The spikes are about 6 foot long & inserted by a hammer head attached to a air compressor tool thru the ballast into the sub strata underneath .

Cheers Tom in Oz [just back from climbing the Great Wall in China ]
thanks 3 users liked this useful post by Tom Jessop
Offline ozzman
#6 Posted : 28 May 2015 00:46:31(UTC)

Joined: 23/11/2007(UTC)
Posts: 1,828
Location: Sydney, Australia
I have seen the same here in NSW, but forget where (somewhere around Sydney).
Z Scale
"Never let the prototype get in the way of a good layout"
Offline DaleSchultz
#7 Posted : 24 June 2015 20:14:18(UTC)

United States
Joined: 10/02/2006(UTC)
Posts: 3,997
Meanwhile I have found why Märklin tracks really have center studs...

it is to check that the track is straight when laying it

laser line

Intellibox + own software, K-Track
My current layout: https://cabin-layout.mixmox.com
Arrival and Departure signs: https://remotesign.mixmox.com
thanks 9 users liked this useful post by DaleSchultz
Offline waorb
#8 Posted : 24 June 2015 21:55:59(UTC)

Joined: 31/05/2011(UTC)
Posts: 868
Location: Brazil
Nice excuse to use the laser pointer! ThumpUp


thanks 1 user liked this useful post by waorb
